Specifications
| Item | Specification |
| Nominal Capacity | 2950mAh (0.2C, 2.75V discharge) |
| Minimum Capacity | 2850mAh ( 0.2C, 2.75V discharge) |
| Charging Voltage | 4.35V±0.05V |
| Nominal Voltage | 3.78V |
| Charging Method |
CC-CV (constant voltage with limited current ) |
| Charging Current |
Standard charge: 1475mA (Reconmendation) Rapid charge: 2950mAh |
| Standard Charging Time |
Standard charge: 3.0hours Rapid charge: 2.5hours |
| Max. Charge Current | 2950mA (ambient temperature 25°C) |
| Max. Discharge Current | 5900mA (ambient temperature 25°C) |
| Discharge Cut-off Voltage | 2.75V |
| Cell Weight | 48.0g max. |
| Cell Dimension |
Height: 65.00mm max. Diameter: 18.40mm max. |
|
Operating Temperature (Ambient) |
Charge: 0 to 45°C Discharge: -20 to 60°C |
| Storage Temperature |
1 year: -20 to 25°C 3 months: -20 to 45°C 1 month: -20 to 50°C |
Applications
Various Portable Devices such as N/PC, DSC, DVC
Cellular phone, note PC ect.
DVD/DSC/DVD/Portable LCD TV ect.
Portable CD player, MD player, Semiconductor-driven audio ect.
