| Model | EV1865-4S2P |
| Part No. | 4002-05-AL8374 |
| Cell origin | Selected A Grade Samsung Li-ion cells |
| Nominal Capacity | 7000mAh (customized) |
| Nominal Voltage | 14.8V |
| Std.Charge Voltage | 16.8V |
| Std.Charge Current | 2A |
| Std. Discharge Current | 0.2C (1.4A) |
| Max. Discharge Current | 5A (Customized) |
| PCM built-in | Yes |
| Connector | JST-VH |
| PCM function | Protect battery from over-charge, over-discharge and short circuit |
| Discharge Cut-off Voltage | 11.4V |
| Dimension | (L)135.00mm*(W)36.40*(H)36.40mm approx. |
| Weight | 400g max. |
| Operating Temperature |
Charge: 0~45dgC Discharge: -20~60dgC |
