30A High Drian Murata Sony US18650VTC4 Lithium ion Rechargeable Battery
With 30A continuous high discharge current
|
Item |
Specifications |
|
Nominal Voltage |
3.6V |
|
Capacity
|
Typical: 2100mAh
Minumum: 2000mAh
|
|
Charging Voltage |
4.20V |
Max. continuous discharge
Temperature cut-off 70°C |
30A(at 25°C) |
Discharge cut-off voltage
End of discharge |
2.5V
(2.5V discharge cut-off is better in cycle life ) |
|
Max. Discharge and time |
60A (75 seconds) |
|
Cell weight |
48.0g max. |
|
Cell dimension |
18.00*65.00mm |
Operating temperature
(surface temperature) |
Charge : 0 to 50
(recommended recharge release < 45°C)
Discharge: -20 to 75
(recommended re-discharge release < 60°C)
|
|
Top Type |
Flat top |
Ideal for high performance electronic devices such as power tools, drills, e-bikes, vacuum cleaner, one wheel/ single wheel e-scooters, electric motorcycle, etc.
Cell should be used with PCM assembling for a safe operating condition.
OEM battery pack orders are available.
